Conductivity Point(s) Level Switch Conductive Liquids (Model – LWS)

Conductivity Point(s) Level Switch Conductive

Applications:

• Suitable for conductive liquids like water.
• Top mounting & side mounting options.
• Minimum and maximum fail safe field selectable.
• Single point/multipoint/pump-control switching.
• Process temperature max 200 ºC.
• Process pressure max. 3 bar.

features:

• Compact size.
• Integral version with universal power supply (15 to 60 VDC & 15 to 260 VAC).
• Low power consumption.
• No calibration required.
• Various customized process connections like Threaded/Flanged.
• Remote electronics version available on request.
• Exd version available-suitable for gas group IIC, T6 as per IEC 60079-1-2007 & IEC 600529-2001.
