Capcitance Point(s) Level Switch (Model – LMC)

Capcitance Point(s) Level Switch

Applications:

• Suitable for non-sticky liquids and solids.
• Suitable for side as well as top mounting.
• Single point/multipoint/pump control switching on single probe.
• Minimum and maximum fail safe field selectable.
• Process temperature max 600 ºC (ceramic insulation).
• Process pressure max. 15 bar.
• PTFE coated for corrosive and conductive liquids.

features:

• Compact size.
• Universal industrial power supply (15 to 80 VDC & 15 to 260 VAC).
• Low power consumption.
• Easy dip switch calibration.
• Customized process connections like Threaded/Flanged/Hygienic etc.
• Remote electronics version available on request.
• Exd version available-suitable for gas group IIC, T6 as per IEC 60079-1-2007 & IEC 600529-2001.
